High-Speed Compact Type 6 Axis Cobot Industrial Collaborative MIG Laser Welding Machine With Robot

Taiyi Laser Technology Company Limited
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

High-Speed Compact Type 6 Axis Cobot Industrial Collaborative MIG Laser Welding Machine With Robot

Brand Name : TAIYI

Model Number : TY-HS6018

Certification : CE

Place of Origin : Guangdong, China

MOQ : 1

Price : Contact us for the price

Payment Terms : T/T, Western Union, MoneyGram, L/C

Supply Ability : 200 Sets/month

Delivery Time : 15-30 work days

Packaging Details : Export standard packing

Condition : New

Warranty : 2 Year

Applicable material : Metal

Keywords : 6 Axis Welding Robot

Custom : Accept

Contact Now

High-speed Compact Type 6 Axis Cobot Industrial Collaborative MIG Laser Welding Machine with Robot

High-Speed Compact Type 6 Axis Cobot Industrial Collaborative MIG Laser Welding Machine With RobotHigh-Speed Compact Type 6 Axis Cobot Industrial Collaborative MIG Laser Welding Machine With RobotHigh-Speed Compact Type 6 Axis Cobot Industrial Collaborative MIG Laser Welding Machine With RobotHigh-Speed Compact Type 6 Axis Cobot Industrial Collaborative MIG Laser Welding Machine With Robot

TECHNICAL GUIDANCE FOR ONTOLOGY

Robotic Arm Parameters

MaxArmspan

1077mm

Payload

7kg

Repeat Positioning

±0.02mm

ToolMax speed

3000mm/s

ControlBus/Freq

EtherCAT/1KHz

Rated power

260W

Temperature

-5~55℃

Humidity

5%~90%RH,non-condensing

Installation mode

Arbitrary angle

Protection Degree

IP65

weight

21kg

Noise level

≤60dB

Work port

1/0 Port

24V/18;DI:2D0:2AI

Tool Pot

COM Port

24V/1A;1RS485:1 EtherCAT

Joint Movement Parameters

Iotion Range

J1

-360°“360°

J2

-360°"360°

J3

-165°“165°

J4

-360°"360°

J5

-360°360°

J6

-360°“360°

Max Speed

J1

210°s

J2

210/s

J3

210°/s

J4

360°/s

J5

360°/s

J6

360°/s

High-Speed Compact Type 6 Axis Cobot Industrial Collaborative MIG Laser Welding Machine With RobotHigh-Speed Compact Type 6 Axis Cobot Industrial Collaborative MIG Laser Welding Machine With RobotHigh-Speed Compact Type 6 Axis Cobot Industrial Collaborative MIG Laser Welding Machine With RobotHigh-Speed Compact Type 6 Axis Cobot Industrial Collaborative MIG Laser Welding Machine With RobotHigh-Speed Compact Type 6 Axis Cobot Industrial Collaborative MIG Laser Welding Machine With Robot
